Minimum Window Size | 11.81*15.75 (in) |
Applicable Window | all types of flat windows |
Auto Spray (Y/N) | Yes |
Manual Spray (on APP) | Yes |
Spray Width(cm) | Beyond the edge ≤1cm |
Spray Length (front)(cm) | ≤30 |
Spray Uniformity (variance) | ≤0.5 |
Ratio of Spray Coverage | ≥70% |
Max Accumulated Spray Area of Water Tank(Fast Mode, ㎡) | 40±3 |
Method of Spray | 6 |
Self-adaptive Spray Volume (Y/N) | Yes |
Number of Spray Nozzles | with plastic nozzles |
Material of Wiping Pad | Micorfiber(both sides) |
Water Tank Empty Reminding (Y/N) | Yes |
Frame Distance Detection (Y/N) | Yes |
Water Tank Capacity(ml) | 60±5 |
Cleaning Mode | Fast Cleaning Mode, Deep Cleaning Mode, Thorough Cleaning Mode, Edge Cleaning Mode, Spot Cleaning Mode, Zone Cleaning Mode, Heavy-Duty Cleaning Mode |
Intelligent Route Planning | Yes |
Power-off protection | Yes |
Auto Back to Start Point | Yes |
Voice Report | Yes |
Length of Power cord (m) | 5.5 |
Length of Safety Rope (m) | 1 |
Length of Extension Cord (m) | No |
Cleaning Solution (ml) | No |
Cleaning Cloth Size (m㎡) | 260mm*251mm |
Robot Size (mm)(l/w/h) | 271*271*77 |
Weight of Robot (kg) | 1.6±0.1 |
Station Dimension (mm)(l/w/h) | 312*215*327 |
Weight of Station (kg) | 5.5±0.2 |
Working Time per Charge (min) | 110min±10% |
Charging Time (H) | ≤3h |
Working Speed (min/㎡) | 1min45s±15s(Fast Mode) |
Battery Specifications (Type, mAh) | Lithium 4500mah |
Battery Voltage(V) | 24 |
Battery Weight (g) | ≈1330 |
Power off protection time(Full charge) | 30min |
Gross Weight of Carton Box (Kg) | 8.5 |
Size of Carton Box (mm)(l/h/w) | 380*297*406 |
Split Drive Tech (Y/N) | No |
Intelligent Climbing System | Yes |
Type of Blower Fan | Brushless Motor |
Suction Power while moving(Pa) | 2800 |
Max. Suction Power(Pa) | 5500±500 |
Cleaning Efficiency in Default Mode (1X1㎡) | 1min45s±15s(Fast Mode) |
Path Planning Tech | WIN-SLAM 4.0 |
Cleaning Mode | Fast Cleaning Mode Deep Cleaning Mode Thorough Cleaning Mode Edge Cleaning Mode Spot Cleaning Mode Zone Cleaning Mode Heavy-Duty Cleaning Mode |
Return to Initial Spot(Y/N) | Yes |
Min. Detectable Height of Obstacle(mm) | 4 |
Min. Detectable Height of Frame(mm) | 2 |
Frame Detection (Y/N) | Yes |
Breakpoint Continuation (Y/N) | Yes |
APP Control | Yes |
Manual Control (on APP) | Omnidirectional remote control |
Min. Window Size (cm) | 30*40 |
Applicable Window Type | all types of flat windows |
Applicable Frame Type | with Frame & Frameless |
Min. Glass Thickness (mm) | 3 |
Dimension of WINBOT(mm, L*W*H) | 271*271*77 |
Weight of WINBOT (kg) | 1.6±0.1 |
Auto Take-up Rope (Y/N) | Yes |
Speed Control of Take-up (Y/N) | Yes |
Load Detection of Take-up (Y/N) | Yes |
Compound Cable (Y/N) | Yes |
Length of DC cord (m) | 5.5 |
Auto releasing cord with low resistance(Y/N) | Yes |
Safety lock for releasing cord (Y/N) | Yes |
Power-off Protection (Y/N) | Yes |
Power-off Protection Duration (min) | 30 |
Auto return in low battery status (Y/N) | Yes |
Auto take-up in low battery status (Y/N) | Yes |
Extra Weight for Protection (Y/N) | Yes |
Weight of Station(kg) | 5.5±0.2 |
Suction Cup (Y/N) | Yes |
El control of Suction Cup(Y/N) | Yes |
Max. Adsorption Power(N) | ≥800 |
Dimension of WINBOT(mm, L*W*H) | 271*271*77 |
Battteries Capacity (Type, mAh) | Lithium 4500mAh |
Battery Nominal Voltage (V) | 24 |
Typle of Blower Fan | Brushless Motor |
Battteries Capacity (Type, mAh) | 98.55 |
Weight of WINBOT (kg) | 1.6±0.1 |
Weight of Batteries (g) | ca. 1330 |
Number of Batteries | 12 |
Rated Power (W) | 126 |
Powering Mode | Battery-powered operation /Plugged-in operation |
Rated Voltage (V) | 24 |
Charging Time (H) | ≤3 |
Cleaning Efficiency in Default Mode (1X1㎡) | 1min45s±15s(Fast Mode) |
Battery Life (min) | 110min±10% |
One-time Working Area in Fast Cleaning Mode(㎡) | ca. 55㎡ |
One-time Working Area in Deep Cleaning Mode(㎡) | ca. 22㎡ |
Control Panel (Y/N) | Yes |
One-key Switch on & off (Y/N) | Yes |
One-key Return (Y/N) | Yes |
Voice Reminder (Y/N) | Yes |
Dimension of Wiping Pad (LengthxWidth mm) | 260*251 |
Support OTA Upgrade (Y/N) | Yes |
Length of DC cord (m) | 5.5 |
Length of AC cord (m) | 1.8 |
Length of Backup Safety Rope (m) | 1 |
Filling Nozzle (Y/N) | Yes |
User Manual | 1 |
Number of Wiping Pad | 2 |
Carabiner | 1 |
Safety Rope | 1 |
CONTENTS | WINBOT*1, Station*1, Safety Rope*1, Carabiner*1, Wiping Pad*2, Cleaning Solution*1(Empty Bottle), User Manual*1 |
WINBOT | 1 |
Station | 1 |
Package Net Weight (Kg) | 7.2 |
Package Gross Weight (Kg) | 8.5 |
Dimension of Packaging (mm, L*W*H) | 380*297*406 |
